ARRI ALEXA 35 Live Xtreme
ActiveUpdated by GEARMATH
High-speed live multicam camera based on the ALEXA 35 Xtreme, adding ARRICORE recording and sensor frame rates up to 660 fps for slow-motion replays in broadcast productions.
View: Blueprint · Photo
Technical Registry
Sensor
| Sensor | Super 35 ARRI ALEV 4 CMOS, Bayer pattern |
|---|---|
| Sensor resolution | 4608 x 3164 (27.99 x 19.22 mm) |
| Dynamic range | 17 stops |
| Exposure index | EI 160 - 6400 |
| Sensor frame rates | 0.75 - 660 fps |
| Built-in ND | Clear, 0.6, 1.2, 1.8 motorized |
Recording
| Recording formats | ARRIRAW, ARRICORE, Apple ProRes 4444 XQ / 4444 / 422 HQ |
|---|---|
| Recording media | Codex Compact Drive 1TB / 2TB, Compact Drive Express 1TB |
| Video outputs | 2x 12G-SDI |
Physical
| Weight | ~6.3 kg (body with PL mount and Fiber Camera Adapter) |
|---|---|
| Lens mount | ARRI LPL (LBUS); PL, EF and Leitz M options |
