ARRI LPM-1 Live Production Monitor
ActiveUpdated by GEARMATH
8.5-inch 1500-nit operator monitor for the ALEXA 35 Live system, with physical tally lights, camera number display, touchscreen access to the full camera menu and 12G-SDI in and loop.
View: Blueprint · Photo
Technical Registry
Monitoring
| Resolution | 1920 x 1200 |
|---|---|
| Active screen size | 216.80 x 135.50 mm (8.5 in) |
| Brightness | ~1500 cd/m² max |
| Contrast | 900:1 |
| Aspect ratio | 16:10 |
| Viewing angle | 160° |
Physical
| Connectors | PWR IN (3-pin Fischer), VF (CoaXPress), ETH, TALLY IN, 12G-SDI in, 12G-SDI in/out, USB-C |
|---|---|
| Power consumption | < 24 W |
| Power input range | 10-34 V |
| Dimensions | 247 x 196 x 56 mm |
| Weight | 1.7 kg |
