ARRI M8 HMI Lamphead
ActiveUpdated by GEARMATH
800 W open-face HMI using ARRI's lens-less MAX reflector for a punchy, even beam from 15 to 62 degrees, in an 8.5 kg head that dims from 50 to 100 percent via its ballast.
View: Blueprint · Photo
Technical Registry
Lighting
| Lamphead type | Open Face with Facetted Reflector, 800 W |
|---|---|
| Lamp type | Metal Halide 800 W/SE (Only 800 W, no 575 W lamps) |
| Power consumption | 800 W |
| Colour temperature | 6,000 K |
| Beam angle | 15° to 62° |
| Dimming | yes, 50 to 100 % via ARRI Ballast Unit |
| Voltage range | 90 to 130 V / 180 to 250 V |
| Lamp base | G22 |
Physical
| Weight (net) | approx. 8.5 kg |
|---|---|
| Dimensions (HxWxL, excl. pin) | 458 x 350 x 310 mm |
| Lens / UV glass diameter | 200 mm |
| Accessory diameter | 230 mm |
| Mounting | Spigot 28 mm / 1 1/8" (1.1") |
| Mains plug | VEAM |
| Protection class / IP rating | I / IP23 |
