Kiloview N6 HDMI NDI Converter

Active
Kiloview·monitoring·TBD

Updated by GEARMATH

1080p60 bidirectional converter between HDMI 2.0 and NDI HB, HX2 or HX3 using SpeedHQ, H.264 or H.265, with HDMI loop-out, PoE or 12 V DC power and a cold-shoe mount.

View: Blueprint · Photo
Kiloview N6 HDMI NDI Converter
ShareSuggest a changeROI Calculator
Manufacturer page · www.kiloview.com

Technical Registry

Monitoring

Video ResolutionInput support:; 1920*1080p 60/59.94/50/30/29.97/25/24/23.98fps; 1920*1080i 60/59.94/50fps; 1280*720p 60/59.94/50/30/29.97/25/24/23.98fps; Output support:
Video Encoding and DecodingSpeedHQ(NDI), H.264(AVC), H.265(HEVC)
Streaming ProtocolsNDI HB/NDI HX2/HX3
Color SpaceEncoding; NDI HB: YUV 4:2:2; NDI HX: YVU 4:2:0; Decoding; NDI HB: 4:2:0, 4:2:2; NDI HX: 4:2:0
Color Depth8-bit
Audio Encoding and DecodingNDI Audio, AAC-LC, more audio formats and channels available through custom development
Audio SamplingFixed at 48 kHz
Audio ChannelsEncoding: 2 channels; Decoding: 2 channels
PTZ ControlUSB-to-serial (RS-232/RS-485/RS-422) and network protocols (Sony Visca, Pelco-D/P) for external PTZ control

Physical

Video Port1 × 1080p60 HDMI 2.0 input; 1 × 1080p60 HDMI 2.0 output for decoding/loop-out for encoding
Interlaced Video SupportInterlaced video input, with encoding output limited to progressive format only
Audio Port1 × 3.5mm Line in/Line out
Network Port1 × 1000Mbps Ethernet port (support PoE)
USB Port1 × USB 3.0 Type-C (USB web cam supported)
MountingCold shoe adapter
Power SupplyDC 12V （5.5/2.5）or PoE
Power Consumption6W (Max)
Weight500g
