Panasonic AW-UER200 4K PTZ Camera with Roll
ActiveUpdated by GEARMATH
PTZ camera that adds a motorised roll axis to pan and tilt, built around a 1.2-type 5K global-shutter sensor with 22x optical zoom, 12G-SDI, HDMI 2.0 and genlock.
View: Blueprint · Photo
Technical Registry
Sensor
| Imaging Sensor | 1.2-type Global Shutter 5K MOS x1 |
|---|---|
| Effective Pixels | Approx. 14.0 MP |
| Lens | Motorized optical 22x zoom, F2.8 to F4.8 |
| Zoom | Optical 22x; i.Zoom UHD 28x, FHD 35x; D.Extender 1.4x |
| Horizontal Angle of View | 80° (wide) to 4° (tele) |
| Horizontal Resolution | 1,800 TV lines (UHD, centre, wide end) |
| Pan/Tilt Speed | 0.004°/s to 180°/s |
| Roll Speed | 0.08°/s to 720°/s |
| Pan Range | ±175° |
| Outputs | 12G-SDI, 3G-SDI x2, HDMI 2.0 4:2:2 10-bit |
Physical
| Power | 12 V DC or PoE++ (IEEE802.3bt) |
|---|---|
| Mass | Approx. 9.0 kg (excl. mount bracket) |
| Dimensions | 270 x 324 x 258 mm |
| Sync Input | Black burst / tri-level sync |
| Control | LAN (RJ-45), RS-422A |
