Schoeps CMC 6xt Microphone Amplifier
ActiveUpdated by GEARMATH
Extended-bandwidth version of the CMC 6 Colette amplifier with response to 60 kHz, used for hi-res recording and sound-design work where capsules reach beyond 20 kHz.
View: Blueprint · Photo
Technical Registry
Audio
| Frequency Range | 20 Hz - 60 kHz |
|---|---|
| Low Cut | 20 Hz, 12 dB/oct. |
| Max Output Voltage | 1 V (0 dBV) with 1 kΩ load |
Physical
| Powering | P48 / >20 V, P12 / >10 V |
|---|---|
| Current Draw | 4 mA (P48), 8 mA (P12) |
| Output | XLR-3M, analog, 1 channel |
| Output Impedance | 42 Ω |
| Length | 116 mm |
| Diameter | 20 mm |
| Weight | 60 g |
