Schoeps MSTC 74 ORTF Stereo Microphone

Active
Schoeps·audio·TBD

Updated by GEARMATH

Fixed ORTF stereo microphone with two MK 4 cardioids spaced 17 cm at a 95 degree recording angle, output on a single XLR-5M for stereo ambience and effects.

View: Blueprint · Photo
Schoeps MSTC 74 ORTF Stereo Microphone
ShareSuggest a changeROI Calculator
Manufacturer page · schoeps.de

Technical Registry

Audio

Polar PatternCardioid (2× MK 4)
Frequency Range40 Hz - 26 kHz
Sensitivity-36,5 dB (V/Pa), 15 mV/Pa
Self Noise (A-weighted)14 dB
SNR (A-weighted)80 dB
Max SPL (0.5% THD)135 dB-SPL
Low Cut20 Hz, 12 dB/oct.
Recording Angle95°
Stereo TechniqueORTF
Max Output Voltage1,8 V (5 dBV) with 1 kΩ load

Physical

PoweringP48 / 30-52 V, P12 / 11-13 V
Current Draw2 mA per channel (P48)
OutputXLR-5M, analog, 2 channels
Output Impedance50 Ω
Capsule Spacing17 cm
Weight232 g (with capsules)
