Schoeps BLM 03 C Boundary Capsule
ActiveUpdated by GEARMATH
Half-space boundary-layer capsule for the Colette system that mounts flat on floors, walls or tables, used for stage, conference and car-interior recording.
View: Blueprint · Photo
Technical Registry
Audio
| Polar Pattern | Half-space |
|---|---|
| Frequency Range | 20 Hz - 26 kHz, 20 Hz - 43 kHz with CMC 6xt |
| Sensitivity | -36 dB (V/Pa), 16 mV/Pa |
| Self Noise (A-weighted) | 12 dB |
| SNR (A-weighted) | 82 dB |
| Max SPL (0.5% THD) | 130 dB-SPL with CMC 6, 134 dB-SPL with CMC 6 |
Physical
| Diameter | 80 mm |
|---|---|
| Height | 8,6 mm |
| Weight | 233 g |
