Schoeps MK 8 Figure-8 Capsule
ActiveUpdated by GEARMATH
Figure-of-eight Colette capsule used as the side element in M/S stereo rigs and in Blumlein pairs, with deep side rejection.
View: Blueprint · Photo
Technical Registry
Audio
| Polar Pattern | Figure-of-eight |
|---|---|
| Frequency Range | 40 Hz - 15 kHz, 40 Hz - 15 kHz with CMC6xt (above 20 kHz, the level of -3 dB for the cutoff frequency is not exceeded despite the xt boost) |
| Sensitivity | -38,5 dB (V/Pa), 12 mV/Pa |
| Self Noise (A-weighted) | 17 dB |
| SNR (A-weighted) | 77 dB |
| Max SPL (0.5% THD) | 133 dB-SPL with CMC 6, 137 dB-SPL with CMC 1 |
Physical
| Length | 34 mm |
|---|---|
| Diameter | 20 mm |
| Weight | 18 g |
